Item Details

Specifications
Benefits
Equipment
Engine
Engine Model
Isuzu BB-6WG1XQA-03
Displacement
15.681L
Rated Power
310/1800 kW/rpm
Operating Weight
Std. Operating Weight
72000 kg
Std.Bucket Capacity
4m³
Hydraulic System
Hydraulic Motors - Travel
KYB MSF340/WT14AC00B
Hydraulic Motors - Swing
Toshiba SG20E-117 (Left) SG20E-118 (Right)
Boom Cylinders - Bore
180mm
Boom Cylinders - Stroke
1733mm
Arm Cylinders - Bore
200mm
Arm Cylinders - Stroke
2020mm
Bucket Cylinders - Bore
180mm
Bucket Cylinders - Stroke
1580mm
Service Capacities
Fuel Tank Capacity
970L
Hydraulic Tank Capacity
620L
Engine Oil
47L
Cooling System
57L
Final Drive (each)
15L
Swing Drive (each)
6.0L
Undercarriage
Track Shoes Number
47
Carrier Roller - Perside
3
Track Roller - Perside
8
Working Range
Max.Digging Force - Bucket
356kN
Max.Digging Force - Arm
273kN
Max.Digging Depth
7152mm
Max.Vertical Digging Depth
5129mm
Max. Excavating Distance
11653mm
Min. Swing Radius
5058mm
Transmission
Travel Speed - Highest
12000mm
Travel Speed - Lowest
4.5km/h
Swing Speed
3.1km/h
Gradeability
70%/35°
Std. Operating Weight
89.5kPa
Dimensions
Transportation Length
12000mm
Transportation Width
3440/4188mm
Transportation Height
4771mm
Upper Body Width
3360mm
Cab Height
3700mm
Std.Track Width
750mm
Track Gauge
2690/3250mm
Min.Ground Clearance
875mm
Tail Swing Radius
Track Length
5870mm

HIGH EFFICIENCY AND LOW CONSUMPTION
With the strong power and high reliability, the Isuzu BB-6WG1XQA-03 engine fully ensures the excavator’s stability continuously working in harsh environment, satisfying the customer’s high demand for the stability of engine.
Imported engine with 6-cylinder 4 stroke direct-injection and air intercooler provides strong power and high reliability for highly efficient operation via better combustion performance and lower fuel consumption.



HIGH RELIABILITY
Six-cylinder engine ensures high reliability and stability of the machine as a whole.
With the engine rated power of 310kW, SY700 has a displacement up to 15.68L, which reduces the engine heat load and gives a longer service life.



EASIER MONITORING AND MAINTENANCE
The SANY self-developed LCD monitor ensures safe, precise and stable operation. It can be easily read from various angles under different light conditions. With simple switch on/off design, the monitor is operated easily. It also has function keys for multifunctional operation.



CONFORTABLE AND SAFE CAB ENVIRONMENT
Innovative spacious cab
Silicone rubber shock absorber
Pressure sealed cab
Multipoint air-out
Automatic air conditioner
High-strength top plate
Anti-skid plates
Pump/engine screen
Steel welded falling object protection structure
Insulated panel and fan guard
Hydraulic lockout control

OPTIONAL EQUIPMENT

►FOPS&ROPS Cabin

Half protection cabin

Full protection cabin

Fuel fill pump

Working flash lamp

Travel Acoustic alarm

Rear camera

Long Track

Thick undercover
