Item Details

Specifications
Benefits
Equipment
Engine
Engine Model
Isuzu CC-6BG1TRP
Displacement
6.49L
Rated Power
128.5/2100kW/rpm
Operating Weight
Std. Operating Weight
24200kg
Hydraulic System
Main pump - Maximum flow
2*219lpm
Hydraulic Motors - Travel
2
Hydraulic Motors - Swing
1
Relief Valve - Implement Circuit
34.3mpa
Relief Valve - Travel Circuit
34.3mpa
Relief Valve - Heavy Lift Circuit
28mpa
Relief Valve - Pilot Circuit
3.9mpa
Service Capacities
Fuel Tank Capacity
340L
Hydraulic Tank Capacity
239L
Engine Oil
24.5L
Cooling System
29L
Final Drive (each)
5.5L
Swing Drive (each)
5.3L
Undercarriage
Track Shoes Number
49
Carrier Roller - Perside
9
Track Roller - Perside
2
Working Range
Max.Digging Force - Bucket
175KN
Max.Digging Force - Arm
122KN
Max.Digging Height
9640mm
Max.Digging Depth
6785mm
Max. Excavating Distance
10150mm
Min. Swing Radius
3800mm
Height at Min. Swing Radius
7940mm
Transmission
Travel Speed - Highest
5.5km/h
Travel Speed - Lowest
3.3km/h
Swing Speed
11rpm
Gradeability
70%/35°
Std. Operating Weight
47.6kPa
Dimensions
Transportation Length
9920mm
Transportation Width
2980mm
Transportation Height
3550mm
Upper Body Width
2710mm
Cab Height
2990mm
Std.Track Width
600mm
Track Gauge
2380mm
Min.Ground Clearance
440mm
Tail Swing Radius

The 24200 kg SY220C adopts Isuzu CC-6BG1TRP engine, with 172.5/2100 kW/rmp power force. With the 679N.m@1800 rpm Max. Torque, the 24-ton star medium-sized excavator offers you higher working efficiency.



ADVANCED DYNAMIC CONTROL
The self-developed DOMCS (Dynamic Optimization Matching Control System) intelligent control perfectly matches the engine system and hydraulic driving system, greatly increasing the operating efficiency by 6 percent, while with the fuel consumption reduced by 10 percent.

The matched auto idle speed function is designed for increasing the fuel efficiency and the stability of idling, maximizing the conformability of operation. The variable working modes, including heavy-duty mode, standard mode, light-duty mode and break mode, improves the versatility of the machine in different working environment.



REMOTE MONITORING SYSTEM
Configured with advanced GPRS monitoring system and smart machine alerts, allows SANY to monitor all of their equipment around the world. We keep track of engine hours, fuel usage, location history, alerts and events. If there is a problem with a machine, SANY knows about it immediately. With the remote error diagnosis, the problem could be addressed in real time.



HIGH STABILITY AND RELIABILITY
The upgraded undercarriage adopts the X-shape structure for the lateral beams, featuring high strength and rigidity, excellent torsion and bending resistant performance.



RELATED ARTICLES

SY240C in mountain road digging project

The 24 ton SY240C excavator was used in a mountain road digging project, for the rock clearing work. The rood is located close to the State No.502 Road of Sweden.

OPTIONAL EQUIPMENT

►Track: 700mm/800mm
