Item Details
Specifications
Benefits
Equipment
Engine
Engine Model
ISUZU 4BG1-TABGC-03-C2
Rated Power
72.7 / 2200kW/rpm
Operating Weight
Std. Operating Weight
16800kg
Hydraulic System
Service Capacities
Undercarriage
Track Shoes Number
960mm
Working Range
Max.Digging Height
9185mm
Max.Digging Depth
5165mm
Min. Swing Radius
2670mm
Height at Min. Swing Radius
6805mm
Transmission
Dimensions
Transportation Length
7756mm
Transportation Width
2756mm
Transportation Height
3308mm
Min.Ground Clearance
620mm
Tail Swing Radius
High-efficiency
It adds re-generation function according to frequent use of grapple, the grapple closing & opening speed increase 24%.
Reliability
Strengthened under-carriage and platform, reinforced boom and arm, handle tough work conditions better.
Forceful
Top-class drawbar pulling force(154kN), make transfer easier through bad roads and wetlands.
Energy-saving
Globally renowned electrical control hydraulic pump can realize precise flow control based on loading, mapping it with engine real time power and significantly reduces energy consumption.
