Item Details

Specifications
Benefits
Equipment
Engine
Engine Model
kubota V2607-DI
Displacement
2.615L
Rated Power
43.0/2000kW/rpm
Operating Weight
Std. Operating Weight
5920kg
Std.Bucket Capacity
0.21m³
Std.Boom Length
3m
Hydraulic System
Hydraulic Motors - Travel
Rexroth A6VM80HA1/63
Hydraulic Motors - Swing
Nachi PCR-4B-20A-P-9217A
Service Capacities
Fuel Tank Capacity
130L
Hydraulic Tank Capacity
85L
Engine Oil
10L
Cooling System
5.6L
Undercarriage
Working Range
Max.Digging Force - Bucket
45kN
Max.Digging Force - Arm
33kN
Max.Digging Height
5908mm
Max.Digging Depth
3490mm
Max.Vertical Digging Depth
3025mm
Min. Swing Radius
2555mm
Height at Min. Swing Radius
4780mm
Transmission
Travel Speed - Highest
30km/h
Travel Speed - Lowest
10km.h
Swing Speed
9.6rpm
Gradeability
58%/30°
Std. Operating Weight
296kPa
Dimensions
Transportation Length
5928mm
Transportation Width
1978mm
Transportation Height
2884mm
Min.Ground Clearance
290mm
Tail Swing Radius

High efficiency and low consumption
The Tier 3 kubota V2607-DI Engine can precisely controls the fuel jet according to the various working modes, to make the fuel burn more sufficiently.



Excellent reliability and durability
The self-independently DOMCS dynamic optimized intelligent control system realizes the perfect match of the engine and the main pump, making the movement more fast and also prolonging the service life.



Users friendly design
The brand-new damping system, cab with extra-large view, strengthened noise reduction design, greatly improve the operation experience.

OPTIONAL EQUIPMENT

►Hammer pipe lines

FOPS&ROPS cabin

Long Track

Rubber Track

Travel Motor: Rexroth

Track: 12-16.5-12PR(Tyre)
