Item Details
Specifications
Benefits
Equipment
Engine
Engine Model
Cummins QSB6.7
Displacement
6.7 L
Rated Power
142/2000 kW/rpm
Emission Standard
Tier 4 Final / EU Stage IV
Max.torque
809/1500 N·m/rpm
Operating Weight
Std. Operating Weight
25500 kg
Hydraulic System
Service Capacities
Undercarriage
Working Range
Max.Digging Height
9745 mm
Max.Digging Depth
6705 mm
Max.Vertical Digging Depth
5675 mm
Min. Swing Radius
3800 mm
Height at Min. Swing Radius
3915 mm
Transmission
Dimensions
Transportation Length
10290 mm
Transportation Width
3190 mm
Transportation Height
3255 mm
Upper Body Width
3045 mm
Min.Ground Clearance
470 mm
Tail Swing Radius
