Item Details
Specifications
Benefits
Equipment
UNITS :
METRIC
US
Engine
Engine Model
Cummins QSL8.9-C220-Ⅲ
Max Gross Power
164/2200kW/rpm
Max Gross Torque
1000N·m
Operating
Bucket Capacity
2.7-4.0m3
Tipping Load Straight
5000kg
Weight
Operating Weight
17100±200kg
Hydraulic System
Hydraulic Cycle Times
Servcie Capacities
Transmission
Power Train
Dimensions
Optimum Efficiency
Cummins QSL8.9 Engine: ensures strong power, high efficiency and large displacement.
Multipoint fuel injection allows for immediate throttle response, enhanced fuel efficiency and reduced noise.
Meets Tier 3 emission standard.
Customized DANA Transmission: The DANA axis-shift transmission with electronic control system is used for automatic shifting, maximum efficiency and 10k-hour service life.
F/R handle and fingertips control realize ease of switch between left and right hands.
Solenoid valve + logic control achieve a much smoother shifting and faster response.
High-Pressure Load-Sensitive Hydraulic System: perfect match between speed and power, 10%-15% energy saving.
The 25MPa high-pressure hydraulic system and main valve of large displacement achieve higher breakout and lifting force.
Superior Reliability
Braking System: The full hydraulic electronic control parking brake and dual circuit service brake combine maneuverability and reliability, ensuring a safe operating experience.
Reinforced structural components are adopted for heavy-duty mining applications with a service life reaching 10k hours.
High Fuel Efficiency
The Cummins QSL8.9 engine reduces the fuel consumption of the wheel loader.
The high-pressure load-sensitive hydraulic system and leading hydraulic components distribute the flow on demand, reducing the unnecessary energy loss and saving energy by up to 10%.
Comfortable Operating Experience
Spacious & Quiet Cab
Generous legroom and visibility, 15% larger than other Chinese wheel loaders.
Reduced noise with 78 dB(A) noise level, creating a super comfortable space for the operators.
Ergonomic Design
Large and soft wrist rest with the height easy to adjust.
Enough legroom, comfortable pedal design, and the angle adjustable steering.
